TTTK KT4

Tallinna Trammi- ja Trollibussikoondise AS class KT4 no 51-132

KT4
© Bruse LF Persson

data for the class KT4
Vehicle:  motor car
Class:  4-axled single-ended (4xER)
Company:  Tallinna Trammi- ja Trollibussikoondise AS (TTTK) nytt fönster
Town:  Tallinn
Class:  KT4
Car number:  51-132
Built number:  81
Manufacturer:  CKD Tatra 1981-1990
Gauage (mm):  1067
Length (mm):  181100
Width (mm):  2200
Height (mm):  3110
Weight (kg):  19800
Axel arrangement:  Bo'Bo'
Wheelbase (mm):
Boggie center base (mm):
Wheel diameter (mm):
Wheel tread width (mm):
Type of motor: TE022
Motor power (kW):  4x40
Type of controller:
Type of coupling:
Compressor:
Operating current:
Max speed (km/h):  65
Door arrangement:
Number of passengers:
Out of service:
Note:

Preserved cars:
ingen bild
motorvagn
TTTK KT4 nr T-27


The history of the class (only in Swedish):
Nr 51-123: KT4-SU fd Sovjet köpta 1981 (72 st).
Nr 124-132: KT4-D fd Gera, Tyskland köpta 1996-1998 (9 st).
Nr 128 fd Berlin.
